“APEX” B.O.D. Incubator is specifically designed to cater the needs of incubation and routine determination of Biological Oxygen Demand on Water & Sewage, Cultivation of Bacteria, Storage of Dairy products, Shell life test etc.
- Sturdy Construction.
- Easy moveability.
- Digital Display & Control (Micro Control Based/PID)
- Fully automatic Control system.
- Stainless Steel inner chamber.
- Glass view Window or Full Glass Door.
- Continuous Force Air Circulation.
- Chamber illumination (Optional).
“APEX” B.O.D. INCUBATORS are available in various size, capacity and inner chamber material for various application and uses in Biology, Virology, Oceanography,Water Pollution, Sewage, Agriculture,Dairy Product Food Research. Lab.and other application include cultivation of Bacteria, Shell life Test,Cultivation of insect Varieties for Genetic Studies, Preservation of vaccine and other test demanding constant & uniform temperature below & above ambient.
Double walled construction, exterior of Mild Steel finished in powder coating epoxy paint/enamel paint. Interior made of either STAINLESS STEEL.
Glasswool insulation will be provided between the chambers to minimise heat/cool loss. Glass-window or full glass-door will be provided. The door will be of double walled provided with magnetic gasket,lock and handle. Removable trays at the fix distanc are provided. Forced air circulation is provided for uniform temperature. The entire unit rest on castor wheels for easy moveability.
HEATING & COOLING
Heating by long lasting air/strip heaters provides heating above ambient temperature with electronic digital control and display system. Hermatically sealed compressor coupled with evaporation coil and fan cooled condenser provide cooling below ambient temperature.
CONTROL SYSTEM : Provided on the front top side of the unit for easy assessment,operation & maintenance.
PANEL:The control panel system is consisting of Voltmeter, Ampere meter, Digital display & Control unit-Micro Control Based, Pilot lamp, Mains ON/OFF Switch, Mains Indi., Heating or Cooling cycle indication etc.
- Temperature Range : 5 Deg.C to 50 Deg.C Without illumination-15 Deg.C to 50 Deg.C with illumination.
- Indication Resolution : +/- 0.1 Deg.C.
- Control Accuracy : +/- 1 Deg.C.
- Sensor : Pt-100 type.
- Capacity : Available in various capacities.
- Power Supply : 230 V AC, 50 Hz.
