RO PLANT 1000 LPH
  • 1000LPH RO PLANT
  • RO plant
  • Ro Plant 1000 LPH

RO PLANT 1000 LPH

₹250,000.00

Reverse Osmosis is a process that is used to remove a wide range of salts to give water of a high purity
– Osmosis is a natural process involving fluid flow across a semi-permeable membrane barrier. It is the
process by which nutrients feed the cells in our bodies and how water gets to the leaves at the top of trees.
Water treatment Plant with 1000 liter per hour flow rate is recommended for Industries and corporate offices. It is small mineral water plant at your premises. The Various industrial water demand for their point of use requirement. It is very affordable and low operating cost.
This commercial-grade reverse osmosis water purifier offers superior-quality drinking water and includes a sediment filter, carbon filter, FRP vessel, and RO membrane to help remove impurities from your water source. The sophisticated 5-stage filtration system eliminates up to 99% of germs, bacteria, metals, and other pollutants from the Water giving you a clean & safe drinking experience without adding any kind of unhealthy chemicals or salts like chlorine or fluoride. This RO purifier is perfect for businesses that want healthy filtered water for their employees and customers by providing them with potable grade purified mineralized alkaline Water in abundance all through the year. With quick setup time, this Commercial Reverse Osmosis Purification System is sure to turn out as one of the best investments anyone could

Add to Wishlist
Compare
Categories: , , ,

Description

RO PLANT 1000 LPH

A 1000 lph (liters per hour) RO plant can generate 1000 litres of pure drinking water in a
hour and plant can be ideally used in places where drinking water requirement is 5000 Liters
per day , in case even if the requirement exceeds 5000 liters the plant can be operated
additional hours to meet your requirements but generally 4 – 5 hours of operation is advised
for the efficient use of the plant.

SHORT CONFIGURATION OF 1000  LPH RO PLANT
SL NO. MATERIAL QUANTITY  UNIT DESCRIPTION
1 VESSEL(16*65) (T/B)       3 PCS ( FRP )MULTIGRADE SAND FILTER AND ACTIVATED CARBON FILTER
2 VESSEL(14*65) (T/B)       1 PCS MNO2 CHAMBER (FRP)
3 VESSEL(13*54) (T/B)       1 PCS ALKALINE FILTER (FRP)
4 VACCUM BREAKER       3 PCS IT PREVENTS POTENTIAL WATER CONTAMINATION

BY STOPPING WATER FROM FLOWING BACKWARDS
5 DISTRIBUTION SYSTEM       10 PCS CAPACITY 10M3/H TO 50M3/H
8 RAW WATER PUMP( 1 HP)       1 PCS FLOW RATE OF 3500 LPH
9  MUITIPORT VULVE(40 NB)       3 PCS FLOW-12M3/H
10 20″ JUMBO FILTER       2 PCS FLOW RATE 6000-8000 LPH
12 HIGH PRESSURE PUMP (2-18)       1 PCS MAX PRESSURE 17KGS/CM2, NORMAL OPERATING

PRESSURE- 8-15KGS/CM2
13 SS SKID (1000  LPH)       1 PCS 1000 LPH
14 80*40 MEMBRANE       1 PCS OPERATE AT A PRESSURE BETWEEN 9-15KGS/CM2
15 80*40 MEMBRANE  HOUSING       1 PCS OPERATING PRESSURE 9-15KGS/CM2. MAX PRESSURE

21KGS/CM2
16 FLOW METER       2 PCS 2400 LPH
17 ALUM      20 KG IT IS USED TO REDUCE THE AMOUNT OF PHOSPHORUS

AND FLUORIDE IN THE WATER
18 CHLORINE      30 LTR IT IS USED TO PREVENT CONTAMINATION WITH GERMS.
19 ANTISCALANT      5 LTR IT IS USED TO PREVENT THE SCALING & FOULING OF THE

RO MEMBRANE
20 PRESSURE GAUGE 21KG/7KG      2 PCS TO CALCULATE PRESSURE EACH UNIT IN RO SYSTEM
21 DOSING PUMP       3 PCS CAPACITY – 6LPH ,PUMP FLOW MAX 0-5/HOUR                                                                                                                                                                                                                                                                                        MAXIMUM PRESSURE5-6 BAR
22 RO PANEL       1 PCS IT IS PROVIDED AS A SAFETY MEASURE FOR THE PUMP

& OTHER ELECTRICAL ITEMS.
23 UV SET 1000       1 PCS STAINLESS STEEL 304
